Our first ever Titanium hardtail! The Surface Ti mirrors the geometry of our highly evolved Surface model featuring our most updated design, tuned for all mountain capabilities with rugged trail riding as the priority.
As per the evolution of all our trail bikes the Surface Ti features long front end geometry, slacker head angle, steep seattube angle, short chainstays, and low BB height, all tuned for longer travel (150mm). This frame is designed with 148 boost rear axle spacing and a new yoke, CNC machined from solid titanium for increased tire clearance.
Titanium is most known for it's corrosion resistance and strength to density ratio, the highest of any metallic element. It's half the weight of steel for the same tensile strength and twice as strong as aluminum alloy. In practical terms this means we can use less material (ie. thinner tubing) to achieve the same strength. Combining this with it's ductility means we can create incredibly light frames, but still maintain incredible compliance and ride feel.
Titanium is also much more resistant to fatigue and impact than aluminum alloys, and it's natural protective layer of Titanium Dioxide shields it from the elements.
A perfect balance between carbon fibre, aluminium and steel.
Hub Spacing // Boost 148mm (Axle and Hanger Included)
Headset // 44-56 Semi Integrated
Seat Clamp Size // 35mm
Seatpost Size // 31.6mm
BB // 73mm Threaded, ISCG Mounts
Wheel Size // 29" or 27+
Recommended Fork Travel // 150mm (±10mm)
|PARTS||G1 BEST BUILD|
|FORK||Rock Shox Pike Select +150mm
|STEM||Chromag Hifi 40mm|
|HANDLEBAR||Chromag Cutlass Carbon 25mm Rise, 800mm Wide|
|HEADSET||Cane Creek Forty ZS|
|CRANK||SRAM X1 Carbon|
|BRAKES||SRAM Guide RSC|
|SHIFTERS||SRAM X01 Eagle|
|CASSETTE||SRAM X01 Eagle 10-50t|
|REAR DERAILLEUR||SRAM X01 Eagle|
|WHEELSET||Chromag 29" Phase30 Rims with Chromag Magna Hubs. (Magna40 Rims for 27+)|
|TIRES||Maxxis Minion DHF/DHR|
|SEATPOST||Rock Shox Reverb|
|SADDLE||Chromag Trailmaster LTD|
|CHAIN||SRAM X01 Eagle|
Build options are subject to availability.
To purchase a complete build, please contact us directly. We are happy to answer all your questions about our bikes and products. Call: 604-905-6667 Email: firstname.lastname@example.org
*US pricing applies to all US and International purchases.
Head Tube Badge
Your bike is special. The head tube badge is the finishing touch so we’ve always made a point of taking the time to do something interesting with it. Our head tube badges have changed over the years and are an indication of the time each bike was made. Whether it’s a cast bronze, or polished stainless steel, water cut aluminum or a 3D CNC carving, each one represents our commitment to detail.
As 12mm through axles have proven to be solid, reliable and convenient, we have committed most of our models to utilize this format. Our 12mm dropouts are accurate and tough and feature a removable derailleur hanger with a sturdy interface for strength and reliability. All 2017 models (excluding Monk and Nice Dreams) will follow the 148mm boost spacing.
Our ‘Yokel’ design is a small machined junction on the chainstay that helps accommodate both tire clearance and chainring clearance. Our first versions were huge CNC yokes that bridged the entire front end of the chainstays. Over time we refined this to minimize weight by arranging our chainstay layout asymmetrically and reducing the yoke to a minimal size. It’s one of our most unique frame features and has been copied by other frame makers.
Chain Stay Protector
All Chromags now ship with our injection moulded chain stay protector to help keep the paint fresh and the noise low. These have an adhesive applied, but also slot for zip ties if they come unstuck years down the line, or if you want to apply it to another frame.
|Frame Size||STypical Rider Height: 155cm - 165cm||MTypical Rider Height: 163cm - 174cm||M/LTypical Rider Height: 172cm - 183cm||LTypical Rider Height: 181cm - 192cm||XLTypical Rider Height: 190cm - 200cm|
* Max. post insertion based on Rockshox Reverb
